AKG PCC160 Professional Boundary Layer Microphone

Great act

The PCC160 is a professional boundary layer microphone and an industry standard stage floor microphone. It´s capable of withstanding up to 120dB SPL without distortion. A bass-tilt switch allows the user to tailor the low-end response for particular applications. PCC® (Phase Coherent Cardioid®) technology uses diaphragms so small that any phase cancellations are above the audible range. This results in a wide, smooth frequency response free of phase interference. The PCC160 uses a supercardioid polar pattern that improves gain before feedback and reduces unwanted room noise from the rear.

Specifications:

Audio frequency bandwidth: 50 - 18000 Hz

Equivalent noise level: 22 dB-A

Sensitivity: 22 mV/Pa

Signal to Noise: 72 dB-A

Recommended load impedance: 2000 Ohms

Dimensions (LxWxH): 170 mm x 80 mm x 20 mm

Audio Output

• Type: Switchcraft TA3F
• Contacts: 3-pin

Powering Interface

• Voltage: 12 to 48 V
