ADJ Net4 DMX over Ethernet Node
NET4
Regular price$699.98
Sorry this product is back ordered
This product is available for order from our supplier. Please contact us for delivery dates.
Want to know more about ADJ Net4 DMX over Ethernet Node?
Explore these payment options:
Payment plans from RBC Payplan, learn more
Payment plans from Affirm, learn more
- ADJ
- Shipping Calculated at checkout, most in stock products ship same day
NET 4 is a versatile 4-port DMX over Ethernet node that can be truss mounted with M10 or M12 threads or rack mounted using the optional Aria X2 shelf. It is compatible with DMX-512, RDM, Artnet and sACN protocols, ensuring a broad spectrum of integration possibilities. The 1.7-inch LED display facilitates easy configuration, allowing you to fine-tune settings and monitor status at a glance.
• Line Voltage or Power over Ethernet (PoE) powered
• DHCP or Static IP Address
• 1.7" LCD Display
• Configurable from unit menu or web browser
DMX512
RDM
Artnet
sACN
Physical
M10 & M12 Threads for rigging
Safety eyelet
2x Indoor RJ45 Input & Output
4x 5pin XLR Input / Output
Power
AC Input 95-240V,50/60Hz
PoE 802.3af
AC Power: 15W
PoE Power: 15W
Power Consumption: 3.7W @ 120V and 4W @ 230V
Power Input Protection: Fuse, T1.25A/250 (5.2x20mm)
Thermal
Ambient Operational Temperature: -4°F to 113°F (-20°C to 45°C)
Humidity: 75%
Storage Temperature: 77°F (25°C)
Features
• ArtNet / sACN /DMX, 4 Port Node• Line Voltage or Power over Ethernet (PoE) powered
• DHCP or Static IP Address
• 1.7" LCD Display
• Configurable from unit menu or web browser
Specifications
ProtocolsDMX512
RDM
Artnet
sACN
Physical
M10 & M12 Threads for rigging
Safety eyelet
2x Indoor RJ45 Input & Output
4x 5pin XLR Input / Output
Power
AC Input 95-240V,50/60Hz
PoE 802.3af
AC Power: 15W
PoE Power: 15W
Power Consumption: 3.7W @ 120V and 4W @ 230V
Power Input Protection: Fuse, T1.25A/250 (5.2x20mm)
Thermal
Ambient Operational Temperature: -4°F to 113°F (-20°C to 45°C)
Humidity: 75%
Storage Temperature: 77°F (25°C)
