Antari AF-10CA-5PIN 10in Fan With 5-Pin DMX Controller
AF-10CA-5PIN
Payment plans from Affirm, learn more
- Antari
- Shipping Calculated at checkout, most in stock products ship same day
The Antari AF-10 is a high-velocity fan engineered for professional use, combining power, precision, and durability. Featuring a unique swirl-shaped front cover, they maintain focused airflow while reducing turbulence and noise. The specially designed aerodynamic blades ensure optimal air distribution with minimal sound, making them ideal for stage, studio, and installation environments. Built with robust materials for reliable performance, it can operate with a simple plug to start or integrate with an optional control box for remote operation. Whether for fog dispersion or wind effects, the AF-10 delivers efficient, quiet, and consistent airflow in demanding applications.
Features
- High-Velocity Airflow
- Swirl-Shaped Front Cover
- Low Noise Operation
- Robust Construction
- IP55 Rated Motor
Specifications:
Input Voltage: US Model: AC 100–120V, 50/60 Hz, 0.5A
Input Voltage: EU Model: AC 220–240V, 50/60 Hz, 0.5A
Rated Power: 120V: 60W
Rated Power: 240V: 65W
Ambient Temperature Range: 0°C–40°C (32°F–104°F)
Air Flow: 1913 CFM (60Hz)
Fan Speed: 1640 ± 40 RPM
Noise Level: 51.0 dB (Max Output)
Control Methods: Manual
Control Methods: Timer
Control Methods: DMX512
Control Methods: Wireless (Optional)
Control Methods: Wireless DMX (Optional)
DMX Channels: 1 Channel
Interface: SEETRONIC IP65 Connector (Power)
Interface: SEETRONIC IP65 XLR 5-Pin Connector (DMX)
Included Accessories: Dual Use Bracket
Included Accessories: AFC-1 Fan Control
Optional Accessories: WTR-110 Wireless Module
Optional Accessories: ES-W-DMX Wireless DMX
Dimensions: L326 × W535 × H487 mm
Dimensions: L12.84 × W21.07 × H19.18 in
Weight: 8.2 kg
Weight: 18.08 lbs
