ART STEREO PWM COMPRESSOR/LIMITER
DUALLIMITER
Regular price$199.00
Available to Order
Available from supplier ART — usually arrives to us within
3–8
business days. Get in Touch for details.
Payment plans from Affirm, learn more
- ART
- Shipping Calculated at checkout, most in stock products ship same day
The DUAL LIMITER has a unique design that will enhance the sonic textures of your audio system for years to come. Developed in partnership with studio and live-sound engineers, the DUAL LIMITER is very musical.
The heart of the Dual Limiter is a unique PWM gain control circuit. Combined with its' intelligent detector, the result is a Classic sounding compressor/ limiter without the traditional noise and distortion artifacts.
The DUAL LIMITER was designed and constructed with high quality components, assuring a lifetime of quiet, reliable performance.
Features:
- Two channels of dynamics processing
- Selectable stereo linking of channels
- XLR balanced inputs and outputs
- 1/4" TRS active balanced inputs and outputs
- Variable Attack and Release controls
- Selectable Slope
- Hardwire bypass
- 5-segment Gain Reduction
- LED array
- Internal power supply
- 3-year parts and labor warranty
Specifications:
- Equivalent Input Noise: -97dBu (20-20kHz)
- Input Impedance: 20k Ohms
- Output Impedance: Balanced/Unbalanced - 150 Ohms
- Maximum Input Level: +20dBu
- Maximum Output Level: +20dBu
- Overall Gain: +40dB max
- Frequency Response: 10Hz to 30kHz (+/- 1dB)
- Dynamic Range: >105dB (20-20kHz)
- Attack Time: 0.5mSec. to 50mSec., variable
- Release Time: 100mSec. to 3 Sec., variable
- Slope: 4:1 or >20:1, switchable (OR 2:1 or 1.5:1 when patching output to det. loop input)
- Total Harmonic Distortion: 0.03% (typical) @ 0dBm Out
- Power Requirements: USA - 105 to 125 VAC / 60 Hz, 1/2A fuse, <15W
- Dimensions: 1.75" H x 19" W x 5.9" D (44.5mm x 482.6mm x 150mm)
- Weight: 4.7 lbs (2.1 kg)
