ART 4 CH USB RECORDING MIXER

Art Pro Audio USBMIX4 Four Channel Mixer / USB Audio Interface: A low-noise, Mac and PC compliant recording mixer for home studios or location recording.

The ART USBMix4 is a great starting point for building a personal home studio. Perfect for podcasters, songwriters or at home movie makers looking for a simple solution for recording voiceovers, location recording or adding music to your projects using any Mac or PC.

Features:

• High Performance Low Noise Design
• Switchable +48v Phantom Power (CH1)
• Assignable USB Record Source
• Independent Level Controls for Main and Headphone/Monitor Outputs
• 1/8th-inch Headset Connectors (Mono Mic In and Stereo Headset Out)
• Integrated Class Compliant Plug-and-Play USB Audio for Mac & PC
• Operates on USB Power or 5VDC External Power Supply (Included)

Specifications:

• Input Connections:
  • XLR & ¼-inch Balanced Combi-jack (CH 1 & CH2)
  • ¼-inch TRS Balanced (CH3 & CH4)
  • 1/8-inch TRS Aux/MP3
  • 1/8-inch Headset Mic
• Output Connections:
  • ¼-inch TRS Balanced Main Mix Outputs
  • ¼-inch TRS Stereo Output & Monitor Outputs
  • 1/8th-inch Headset Output
• Signal to Noise Ratio: >90dB Typical (Ref 0dBu)
• Maximum Input Level:
  • +8dBu (Mic)
  • +16dBu (1/4-inch Input)
• Maximum Output Level: +15dBu Main Mix Outputs
• Maximum Gain:
  • >55dB (Mic)
  • >37dB (Instrument)
  • 5dB (CH3 & CH4)
• USB Computer Interface: USB Class Compliant plug-and-play Mac / PC Interface
• Power: Via USB or 5VDC @ 500mA
• Dimensions: 1.75″H x 5.1″W x 7.5″D (45mm x 130mm x 191mm)
