Audix MicroHP Cardioid Condenser Instrument Microphone

Designed, assembled and tested by Audix, the MicroHP is a miniaturized condenser microphone used for professional stage and studio applications. The MicroHP, known for its clarity, excellent transient response, resistance to feedback, SPL handling and ease of operation, is primarily aimed for miking drums and percussion instruments.

The MicroHP is characterized with a uniformly controlled cardioid polar pattern and provides excellent isolation and feedback control on stage as well as natural sound reproduction.

With a smooth and accurate response over a frequency range of 40 Hz - 20 kHz, the MicroHP is lightweight, compact and simple to use. Housed in an aluminum ring and isolated by means of a rubber shockmount system, the MicroHP comes with the DCLAMPMICRO mount for hand percussion. A number of optional accessories are also available which allow the MicroHP to be used on a mic stand or cymbal stand for a wider variety of applications. The MicroHP operates on phantom voltage of 9 - 52 Volts and is supplied with a phantom power adapter, 6’ integrated mic cable and carrying pouch.

Accessories:

• 6’ attached shielded cable with mini XLRf connector
• DCLAMPMICRO - Flexible mini-gooseneck lug clamp for drums, congas and percussion. Aluminum ring with rubber shock mount holder.
• APS910 - 48 V phantom power adapter for use with electret condenser mics
• WS20 - External foam windscreen for reducing wind, sibilance, and pop noise
• P1 - Carrying pouch

Features:

• Miniature condenser lug-mounted microphone
• Manages high SPLs without distortion
• Features DCLAMP mount clip for hand percussion
• Rubber shock mount system to reduce vibration
• Includes APS910 phantom power adapter

Applications:

• Drums
• Hand percussion
• Cymbals, percussion toys

Specifications:

Transducer Type: Pre-Polarized Condenser

Frequency Response: 40Hz - 20kHz

Polar Pattern: Cardioid

Output Impedance: 250ohms

Sensitivity: 6 mV / Pa @ 1k

Equivalent Noise Level: 24dB

Signal-to-Noise Ratio: 70dB

Maximum SPL: ≥140 dB

Power Requirements: 9 - 52 V Phantom Power

Connector: 3-pin mini to 3-pin XLRm (APS910)

Polatiry: Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3

Materials / Finish: Machined Brass Capsule / Black
Finish

Gooseneck: Flexible Steel

Weight: 47 g / 1.6 oz

Length: 30 mm / 1.14 in
