Blackmagic Design Mini Converter SDI to Analog with Power Supply
CONVMASA
Regular price$369.00
Available to Order
Available from supplier Blackmagic Design — usually arrives to us within
7–9
business days. Get in Touch for details.
Payment plans from Affirm, learn more
- Blackmagic Design
- Shipping Calculated at checkout, most in stock products ship same day
The perfect way to convert from SD and HD‑SDI to analog component, s‑video or NTSC/PAL composite. Mini Converter SDI to analog supports all SD and HD input formats up to 1080p30 and includes a down converter for when you need to convert from HD to standard definition analog formats such as s‑video and composite. Audio can be de‑embedded to balanced analog or AES/EBU. Mini Converter SDI to Analog is ideal for converting to older analog equipment when you don’t need the extra cost of the 6G‑SDI 4K model.
Features:
- SDI to Analog Conversion
Specifications:
- SDI Video Inputs: 1 x SD, HD or 1.5G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.
- SDI Video Outputs: 1 x SDI Loop Output.
- SDI Rates: 270Mb, 1.5G
- Analog Video Outputs: NTSC, PAL, S‑Video and component SD/HD from 1.5G‑SDI input.
- Analog Audio Outputs: 2 channels of professional balanced analog audio with standard 1/4 inch jack connections.
- Digital Audio Outputs: 2 channels of balanced AES/EBU audio.
- SDI Redundant Input: Automatically switches over if main SDI input is lost.
- Multi Rate Support: Auto detection of SD, HD or 1.5G‑SDI.
- Updates and Configuration: USB
- Reclocking: Yes
- SD Video Standards: 525i59.94 NTSC, 625i50 PAL
- HD Video Standards: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
- SDI Compliance: SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 424M‑B, SMPTE 425M, ITU‑R BT.656 and ITU‑R BT.601.
- SDI Video Rates: SDI video connections are switchable between SD and HD.
- SDI Video Sampling: 4:2:2
- SDI Audio Sampling: Television standard sample rate of 48 kHz and 24 bit.
- SDI Color Precision: 4:2:2
- SDI Color Space: YUV
- SDI Auto Switching: Auto detection of SD, HD or 3G‑SDI.
- Analog Video Standards: 525i29.97 NTSC, 625i25 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080i50, 1080i59.94, 1080i60
- Analog Color Space: YUV
- Analog Color Precision: 4:2:2
- Format Conversion: HD to SD down converter.
- Software Control: Mac™ and Windows™ software upgrade via USB.
- Internal Software Upgrade: Via included updater application.
- Operating Systems: Mac 10.14 Mojave, Mac 10.15 Catalina or later. Windows 8.1 and 10.
- Settings Control: Mini Switches or USB software.
- Power Supply: +12V universal power supply included with international socket adapters for all countries. Cable tie point.
- Power Consumption: 8.04 Watts
- Operational Voltage Range: 12 ‑ 15V DC
- Operating temperature: 0° to 40° C (32° to 104° F)
- Storage temperature: -20° to 45° C (-4° to 113° F)
- Relative Humidity: 0% to 90% non-condensing
- What's Included: Mini Converter SDI to Analog, 12V universal power supply with international socket adapters
- Warranty: 3 Year Limited Manufacturer's Warranty.
