Chauvet Pro COLORADO-SOLO-EDGE1 1 0.5m IP65 RGBwWL LED Footlight

NewCOLORado Solo Edge 1

This low-profile 0.5-meter IP65-rated RGBwWL LED footlight projects high-quality white light and a full range of color through a single-source lens designed to produce smooth, even output. Featuring fully-controllable RGB marker lights that can be used to cue talent or mark the edge of a stage, seamless end-to-end alignment, and a covered display, this elegant fixture also comes with a stealth filter that enables it to disappear when off.

At a Glance

• Low-profile, 0.5mIP65 rated footlight with full-color and high-quality white light

• Single-source lens for smooth, even output with no distracting points of light and an additional “stealth” filter to help the fixture disappear when off

• Additional, fully controllable RGB marker lights can be used to cue talent or mark the edge of a stage

• Designed for end-to-end use with no gaps or distracting cable mess, and a covered display to keep everything elegant unseen.

Specifications

Optical

• Light Source: 56 LEDs (Quintuple-color-RGBwWL), K 20,000 hours life expectancy
• Color Temperature (range): 2800 to 8000 K
• Color Temperature (at full): 6350K
• CRI (2800): 96.2
• Beam Angle: 111.1° (Horizontal)
• Beam Angle: 120.1° (Vertical)
• Field Angle: 134.1 ° (Horizontal)
• Field Angle: 161.4° (Vertical)
• Lumens: 7,144
• Illuminance (total): 104 lux @ 5 m
• PWM Frequency: 1000Hz, 2000Hz, 4000Hz, 6000Hz, 25KHz or 64KHz
• Selectable PWM: 1000Hz, 2000 Hz, 4000Hz, 6000Hz, 25KHz or 64KHz

 Dynamic Effects

• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Framing Shutters: No
• Strobe Rate: 0 to 30Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Modes: 4
• Dim Curves: 4
• Built-in Automated Programs: Yes
• Customizable Programs: Yes
• Recall Custom Programs: Yes/No

 Construction / Physical

• Dimensions: 19.68 x 8.85 x 2.51 in (500 x 225 x 64 mm)
• Weight: 12.6 lb. (5.7kg)
• Exterior Color: Black
• Housing Material: Aluminum alloy and Aluminum diecast

 Connections

• Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Power Output: Seetronic Powerkon IP65
• Data Connectors: 5-pin XLR
• Cable Length (power): 5 ft (1.5 m)

 Control

• Control Protocol: Art-Net, DMX, sACN
• DMX Channels:
  1 Cell: 5, 6, 6, 6, 6, 7, 11, 12, 12, 13, 14 or 21
  2 Cell: 8, 9, 9, 10, 12, 19, 21, 22, 23 or 37
• Art-Net Channels:
  1 Cell: 5, 6, 6, 6, 6, 7, 11, 12, 12, 13, 14 or 21
  2 Cell: 8, 9, 9, 10, 12, 19, 21, 22, 23 or 37
• Modes/Personalities: Personalities (22)
• Frequency (operating): 1000Hz, 2000Hz, 4000Hz, 6000Hz, 25KHz or 64KHz

 Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking:
• Power and Current: 126 W, 1.05 A @ 120 V, 60 Hz
• Power and Current: 125 W, .61 A @208 V, 60 Hz
• Power and Current: 125 W, .55 A @230 V, 50 Hz

 Certifications / Qualifications

• CE, MET, ROHS
• IP Rating: IP65, outdoor/wet, with pressure equalizing M6 GORE valve
• Temperature (Ambient): 5 °F to 113 °F (-15 °C to 45 °C)

 What's Included

• COLORado Solo Edge 1
• Seetronic Powerkon IP65 power cord
• Power and Data linking cables
• Stealth Filter
• Omega bracket with mounting hardware

 Optional Accessories

• Professional Clamps : CTC-50HC, CTC-50HCN
• Riglink TR1 Cables
• Riglink IP DMX cables
• Riglink IP Network cables
