LCG WIDMX Receiver Battery

Overview of LCG WIDMX Receiver Battery

LCG-WIDMX RECEIVER BATTERY is a user-friendly operation that simplifies all the complex communication protocols makes it possible for the users to plug and play.  2.4GHz ISM Band, license-free worldwide,  FHSS with 79 Channels, interference-free operation, 32-bit ARM processor, DMA transfer without delay,  Built-in Wireless Solution compatibility mode, Group Mode, easy plug-and-play operation; Pairing Mode, supports more transmitter universes.

Features:

• Built-in rechargeable lithium battery
• Standard DMX512 3-pin XLR
• One-touch operation with a Tri-color status indicator
• Built-in Wireless Solution Compatibility Mode
• Five modes to choose from, as below;

1. Red mode; Custom signal compatible such as WIDMX.
2. Green mode; Sweden compatibility (Wireless Solution) receiver
3. Blue mode; Sweden compatible (Wireless Solution) transmitter
4. Yellow mode; Standard 2.4G compatible
5. Purple mode: W-DMX G4 Transmit

• Band: 2.402GHz – 2.480GHz, ISM, 79 channels
• pread spectrum: FHSS, 1100 hops / sec
• Modulation: GFSK
• Maximum Transmit Power: 23dBm
• Receiver Sensitivity: -94dBm

 Specifications:

• Power: DC 5V ± 10%
• IP20
• Size：85 x 18 x 18mm
• Weight: 110 g
