Mooer M702 E7 Synth Effects Pedal

E7 Polyphonic Guitar Synth Pedal

E7 is the MOOER Polyphonic Guitar Synth Pedal and is the second pedal of the MOOER New Micro series. As a brand-new design Micro series, we have added 7 LED indicators on the right side of the shell, providing more possibility to the New Micro series.
E7 can transform your guitar into a typical electronic synthesizer, without the need for special pickups or instrument modifications. It is named E7, for its seven different MOOER custom synthesizer tones. Each tone with an individual arpeggiator, high/low-frequency cut, attack, and speed function, allows users to shape the tone in their mind easily, and explore the horizon of tone with the E7.

Features

• 7 different types of brand-new MOOER SYNTH tones
• Individual Arpeggiator for each tone
• 7 slots for storing users’ presets
• Firmware upgradeable via USB

Specifications

• Input: 1/4" mono jack (impedance 2.2M Ohms)
• Output: 1/4" mono jack (impedance 100Ohms)
• Power supply: 9V DC transformer (internal negative external), MOOER Micro Power is recommended
• Current Draw: 150mA
• Dimensions: 93.5mm(D) x 42mm(W) x 52mm(H)
• Weight: 155g
• Accessories: User Manual
