RDL D-CIJ3 Unbalanced Input Module

The D/S-CIJ3 is the ideal choice in installations requiring the passive mixing of two unbalanced line-level audio sources to feed a mono-balanced (or unbalanced) audio line.

The D/S-CIJ3 is a completely unbalanced line-level audio input module. The front panel features two gold-plated phono jacks and a single stereo mini-jack, intended for mono or stereo consumer-level sources. An input signal may be connected to either the phono jacks or the mini-jack. The left and right signal inputs are combined and balanced through audio transformers configured to reject induced hum. A mono line-level output is provided on the rear-panel detachable terminal block for connection to a 10 kΩ or higher input impedance line-level module or equipment input.

Features:

• Stereo Inputs to Mono Output
• Stereo Inputs on RCA Jacks and Stereo Mini-Jack
• Unbalanced to Balanced Conversion Without Gain
• Transformer Isolation for Unbalanced Line Inputs
• Hum Cancellation on Unbalanced Line Inputs
• Line-Level Output to Feed 10 kΩ Equipment Inputs
• Output Connections on Detachable Terminal Block
• Mix Stereo Inputs to Mono Balanced
• Available in RDL White/Gray (D-CIJ3)
• Available in Stainless Steel (DS-CIJ3)
