RØDECaster Video S — All-in-One Console for Video & Audio Production

The RØDECaster Video S is a revolutionary all-in-one console for video and audio production, giving you intuitive control over every aspect of your content.

A streamlined version of the RØDECaster Video, it combines powerful video switching, recording, and production tools with a fully integrated professional audio mixer — all in a compact, desktop-friendly package.

From studio shoots and video podcasts to interviews and live streams, the RØDECaster Video S delivers seamless, broadcast-quality results with total ease.

Key Features

• Switch between up to four video sources and five fully customisable scenes
• High-performance octa-core CPU for video and audio processing
• Three HD (1080p) HDMI inputs, one configurable HDMI output, and one multi-function USB-C port for connecting webcams and RØDE USB audio devices
• Two studio-grade Neutrik® combo jacks with ultra-low noise, high-gain Revolution Preamps™ for capturing pristine audio from XLR microphones, instruments, or any other audio sources
• Powerful APHEX® audio processing, including EQ, compressor, noise gate, high-pass filter, de-esser, and the legendary Aural Exciter™, Big Bottom™, and Compellor™ effects
• Media playback, keying, transitions, multi-source scenes, and graphic overlays accessible from the front panel
• Support for network cameras (including PTZ operation) with up to four NDI® inputs and one output via Ethernet, plus dual-cam streaming with the free RØDE Capture app for iOS devices
• 2-inch high-resolution touchscreen and versatile rotary encoder for quick configuration and setting adjustments
• Connect an external SSD via USB to record video or output directly to a computer via UVC
• Remote control, user-assignable graphics and media, custom scene building, audio mixing and effects, and other advanced configuration options via RØDECaster App
• Intelligent auto-switching for seamless hands-free switching of video sources and scenes based on audio inputs
• Dual USB-C audio interfaces for simultaneous connection to two computers and/or mobile devices
• Dual internal wireless receivers for connecting RØDE Series IV wireless microphones
• Stream directly to all major platforms via Wi-Fi or Ethernet and record directly to an external USB storage device, including isolated (ISO) recording for complete postediting flexibility
• Designed and made in RØDE’s state-of-the-art facilities in Sydney, Australia

VIDEO SPECIFICATIONS

Video Input Feeds: 4 simultaneous
HDMI Inputs: 3 Type-A (HDMI 1.4b)
USB (UVC) Inputs: 1 multi-function USB-C for UVC video
HDMI Outputs: 1 configurable – Preview, Program, Multiview, Inputs 1–4
Video Input Frame Rates: 1920×1080p: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60;                               (HDMI only)1920×1080i: 25, 29.97, 30
Video Output Frame Rates: 1920×1080p: 24, 25, 30, 50, 60
Video Streaming Standards: 1920×1080p: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
Video Engine Colour Space / Bit Depth: 4:4:4 RGB / 8-bit
HDMI Input Colour Space / Bit Depth: 4:4:4 RGB, 4:4:4 YUV, 4:2:2 YUV / 8, 10, 12-bit
USB Input Colour Space: 4:2:2 YUV, 4:2:0 YUV (NV12)
HDMI Output Colour Space / Bit Depth: 4:4:4 RGB, 4:4:4 YUV / 8-bit
USB Output Colour Space / Bit Depth: 4:2:2 YUV / 8-bit
Format and Frame Rate Converters: On all HDMI and USB inputs
NDI Protocols: Single TCP, Multicast
NDI Formats: Hx2, Hx3
NDI Video Codecs: H.264, HEVC/H.265, 4:2:0, 8-bit
NDI Audio Codecs: AAC-LC, L-PCM Stereo 2.0 at 48kHz
NDI Interfaces: Wired Ethernet

SWITCHING SPECIFICATIONS

Total Number of Layers: 9 simultaneous in Preview and Program
Downstream Keyers: 2 (overlays and logo)
Chroma Keyers (Green and Blue): 2
Luma Keyer: 1
Media Players: 2 simultaneous
Transitions: SMPTE wipes, dip, and fade
True Preview: Display complete scenes and overlays simultaneously in Preview and Program
Generated Borders: All scenes
Multiview Includes: Program and preview; Live inputs, scene and media thumbnails; Audio mixer and channel status; Recording, network, and storage status; Run time, date, and time information
Media Player Storage: 24GB on-board
Supported Media Formats: Videos: MP4; Images: PNG, JPG; Audio: WAV
Bluetooth: 5.3 (for stereo audio input or phone calls)

AUDIO SPECIFICATIONS

Analog Audio Inputs: 2 combo jacks (microphone, line, or instrument) with Revolution Preamps™
Wireless Audio Inputs: 2 Series IV wireless receivers
Digital Audio Inputs:
• USB 1: 2-in/2-out or multichannel (20-in) output
• USB 1 Chat (via USB 1 port): 2-in/2-out with mix-minus
• USB 2: 2-in/2-out with MFi support
• USB 4: compatible with RØDE USB microphones and RØDECaster Pro II and Duo
Analog Audio Outputs: 2 headphone outputs (1/4-inch)
Audio Processing: APHEX® VoxLab™ processing: per channel                                                        Advanced APHEX® granular processing on each channel: Compressor, Equaliser (EQ), De-esser, Panning, Noise Gate, High-pass Filter, Aural Exciter™, and Big Bottom™
Preamps: Frequency range 20Hz–20kHz; Input gain up to 76dB; Equivalent Input Noise -131.5dBV (A-weighted)
Streaming Sample Rate / Bit Depth: 48kHz / 32-bit
Recording Sample Rate / Bit Depth: 48kHz / 24-bit
Audio Mixer: 18 possible audio sources (9 stereo channels simultaneously): combo 1 & 2 (stereo), wireless 1 & 2, video clips, sounds, HDMI 1, 2 and 3 (each can split for two mono), Bluetooth, 3 USB audio interfaces (computers), and 1 hosting USB audio device (USB microphone)
Outputs with Custom Routing (11 total): live mix, headphone 1, headphone 2, recording, USB 1 Chat, USB 1 Chat, USB 1, USB 2, USB 4, Bluetooth, HDMI A, Network
Note: Each output can be independently configured with custom level, mute status, and level offset settings for each of the 9 inputs.

STREAMING, RECORDING AND SOFTWARE SPECIFICATIONS

Direct Streaming: Real-Time Messaging Protocol (RTMP/RTMPS) over Ethernet or Wi-Fi
Supported Platforms: YouTube Live, Twitch Live, Facebook Live, Twitter/X Live, Custom server
Network: Ethernet (10/100/1000 BaseT) and Wi-Fi 6 (2.4 & 5GHz) for streaming, configuration, remote control with computer and over-the-air updates
RØDECaster App Companion Software:
• Scene Builder – advanced construction of scenes and remote control of device
• Auto-switching – configuration of automatic switching based on audio input
• Audio Mixer – advanced configuration and control of audio sources, processing and routing
• Stream Profiles – configuration for streaming settings and profiles
• Device Configuration – advanced settings and customisations
Storage Media: External USB mass storage device (exFAT format) for recordings
Video Recording: Program feed as H.264/AVC MP4 file with embedded AAC stereo mix
Isolated (ISO) Video Recording: 4 video inputs and 1 Program feed as independent H.264/AVC files (up to 1080p30)
Audio Recording: Stereo mix WAV audio file
Multitrack Audio Recording: 9 independent stereo WAV audio files
Compatible Operating Systems: macOS 11 or later; Windows 10 Version 1803 or later; Windows 11
