Sennheiser EW-DX EM 2 DANTE (R1-9) Two-Channel Digital Rackmount Receiver with Dante (R1-9: 520 to 607 MHz)

Overview of Sennheiser EW-DX EM 2 DANTE (R1-9) Two-Channel Digital Rackmount Receiver with Dante (R1-9: 520 to 607 MHz)

SENNHEISER EW-DX EM 2 DANTE (R1-9)  520 to 607 MHz/ #509357.

The Sennheiser EW-DX EM 2 DANTE is a half-rack, dual-channel digital wireless receiver with Dante networking capabilities and compatible with EW-DX SK bodypack, EW-DX SKM handheld, and EW-DX TS tabletop transmitters. Housed in a rugged, all-metal chassis built to withstand the rigors of professional use, it can either sit on a tabletop or be rack-mounted (with the included rackmount set) for portable rigs and permanent A/V installs.

The wide 80 MHz tuning range, intelligent switching diversity, auto-scan, equidistant tuning grid, and Link Density mode work to provide rock-solid wireless performance and massive channel counts, even in challenging RF environments. Bluetooth capabilities allow you to remotely sync components and change settings from your phone using the Smart Assist app, while Sennheiser's Control Cockpit and Wireless Systems Manager software provide computer-based control for more extensive networked setups. The EW-DX EM 2 DANTE receiver is backward-compatible with EW-D components.

Specifications

System
Audio link frequency ranges
Q1-9: 470.2 - 550 MHz
R1-9: 520 - 607.8 MHz
S1-10: 606.2 - 693.8 MHz
S2-10: 614.2 - 693.8 MHz
S4-10: 630 - 693.8 MHz
U1/5: 823.2 - 831.8 MHz & 863.2 - 864.8 MHz
V3-4: 925.2 - 937.3 MHz
V5-7: 941.700- 951.800 & 953.050 - 956.050 & 956.650-959.650 MHz
Y1-3: 1785.2 - 1799.8 MHz

Bluetooth® Low Energy (BLE) frequency range
2405 - 2480 MHz

Audio frequency response
20 Hz - 20 kHz (-3 dB) @ 3 dBfs

Total harmonic distortion (THD)
≤ -60 dB for 1 kHz @ -3 dBfs input level

Dynamic range
134 dB

System Latency
1.9 ms

RF technology
Intelligent Switching Diversity

Operating temperature
-10 °C - +55 °C (14 °F - 131 °F)

Operating relative humidity
5 - 95 % (non-condensing)
