Shure GLXD6+ Wireless Guitar Pedal Receiver
GLXD6+-Z3
Payment plans from Affirm, learn more
- Shure
- Shipping Calculated at checkout, most in stock products ship same day
Dimensions: 5.4 x 3.7 x 1.89 in. (138 x 95 x 48 mm, H x W x D)
Weight: 19.75 oz (560 g)
Housing: Aluminum alloy
Power Requirements: 9 V - 15 V, 400mA (efficiency level VI power supply)
Spurious Rejection: >35 dB, typical
Gain Adjustment Range: -20 to 40 dB in 1 dB steps
Configuration: 6.35 mm (1/4“) output, Impedance balanced
Impedance: 6.35 mm (1/4“) output, 100 Ω (50 Ω, Unbalanced)
Maximum Audio Output Level: 6.35 mm (1/4“) connector (into 3 kΩ load), +8.5 dBV
Pin Assignments: 6.35 mm (1/4“) connector, Tip=audio, Ring/Sleeve=ground
Audio Input ModesL Tuner or True Bypass
RECEIVER ANTENNA INPUT
Impedance: 50 Ω
Antenna Type: Dual Band Internal Monopole
Maximum Input Level: −20 dBm
* The GLX-D+ Dual Band and GLX-D wireless system components, including rechargeable batteries, are not compatible with each other. A GLX-D+ Dual Band transmitter will not work with a GLX-D receiver, nor vice versa.
