Universal Audio VOLT 876 RACK MOUNT INTERFACE

The UA Volt 876 is a 24-in/28-out 32-bit/192 kHz USB 2.0 audio interface featuring eight digitally-controlled Vintage preamps and eight onboard 76 analog compressors based on the 1176. ADAT I/O allows standalone preamp expansion or connection with Apollo interfaces. Supports up to three linked Volt 876 units for 24 analog preamp channels. Includes two headphone outputs, UAD Console companion software, LUNA DAW, and UAD plug-ins.

Meet legendary analog sound for the whole band.
Volt 876 USB Recording Studio gives serious music producers a next-generation 32-bit / 192 kHz audio interface with eight onboard Vintage preamps and classic 1176-style compressors right on its front panel, providing big analog studio sound to every mic and instrument you connect.

Built by the same team behind the legendary Apollo interfaces, Volt 876 delivers a beautifully integrated recording experience, including full recall of interface settings, mobile iPhone or iPad recording, an award-winning suite of UAD plug-ins and instruments, and UA's breakthrough LUNA Digital Audio Workstation with AI-powered smart recording tools.

Record your Music with Best-in-Class 32-bit Audio
From the team that brought you the game-changing Apollo interface, Volt 876 delivers next-gen 32-bit / 192 kHz sound quality with eight preamps and compressors - perfect for recording larger groups - with more character and tone than any USB interface in its class.

Capture Legendary Sounds with Eight Vintage Mic Preamps
There's a reason UA's 610 tube mic preamp has been heard on records from Ray Charles to Van Halen to Adele - its warmth and presence are unmatched. Volt 876 gives you the same iconic preamp sound using selectable Vintage mode - UA's exclusive tube emulation circuitry that gives your sessions the sound of a studio classic.

Get 1176-Style Compression Tuned for Voice, Guitars, and More
Add album-ready punch and presence with Volt 876's eight onboard 76 Compressors - an innovative analog circuit inspired by UA's famous 1176 Limiting Amplifier. The 76 Compressor features presets to tame voice, guitars, synths, and drums (fast mode). So you can just plug in, pick a setting, and sound great.

All the Connectivity Youll Ever Need with 24 x 28 I/O
Volt 876 gives you 8 x 8 analog connections for mics, instruments, and studio gear, plus two front-panel mic / line inputs with switchable Hi-Z for easy D.I. recording. Need more? ADAT I/O connections let you link up to three Volt 876s to create a 24-channel recording system, or expand Apollo and other ADAT-equipped studios.

Includes UAD Producer Suite - Premium Plug-Ins & Instruments
Volt 876 includes UAD Producer Suite, a premium collection of UAD plug-in titles - from Teletronix LA-2A and UA 1176 compressors to Pultec EQs, PolyMAX Synth, and the Showtime '64 Guitar Amp - giving you the tones of classic studio gear and inspiring instruments right out of the box.

Use with LUNA for Analog Studio Sound and Smart AI-powered Tools
Volt 876 works with all major DAWs. But when you pair it with UA's LUNA DAW you get the incredible sound of an analog studio with powerful hardware-software integration, unlimited tracks, smart AI-powered tools - including "Hey Luna" Voice Control, Instrument Detection, and Tempo Listen - that make recording easier.

Save and Recall All Your Interface Settings
Using the UAD Console app or LUNA, Volt 876 gives you a host of time-saving features, including Assistive Auto-Gain that automatically sets your recording levels, and two low-latency cue mixes with talkback. Plus, you can save your 876's front-panel settings and cue mixes for instant session recall.

iPad & iPhone Mobile-Recording Ready
Recording a big remote session? Plug Volt 876 into your iPad or iPhone, and you can easily create beats and samples, record your band's rehearsals, and edit songs anywhere.

FEATURES

- 24 x 28 USB audio interface with 32-bit / 192 kHz AD/DA
- Eight digitally-controlled microphone preamps with Assistive Auto-Gain and UA’s exclusive Vintage Mode and 76 Compressors for tone-shaping on every channel
- 16 channels of ADAT I/O for further I/O expandability
- Vintage Mic Preamp Mode on each preamp - record with the rich, full sound of eight mic/line preamps with tube emulation circuitry based on the classic UA 610 console
- 76 Compressor on each preamp, based on the UA 1176 compressor - lending clarity and punch to voice, guitars, and more on all eight channels
- Talkback, cue mixing, remote control, alt monitoring, and more using the UAD Console app (previously only available to use with Apollo audio interfaces)
- Use as a complete USB audio interface or as a standalone ADAT expander: link three Volt 876’s in UAD Console for a 24-track system, or add I/O to your existing Apollo rig or third-party interfaces over ADAT
- Includes native UADx plug-ins, as well as numerous plug-ins from third party plug-in developers

Console Integration:
- Remote-control of Volt 876 functions - mic preamp / input conditioning and monitor control
- UI shows Vintage and 76 Comp modes per channel with remote-control over bypass and compression (Fast, Guitar, Vocal)
- Assistive Auto-Gain to effortlessly set recording levels in an instant - like the Apollo X Gen 2
- Talkback, cue mixing control and routing
- Monitor section control of Dim / Mute / Volume
- Multi-unit control over USB
- Loopback for streaming

Specifications

Monitor Outputs
- Two stereo (Main and Alt. Monitors)
- Main (Line Out 1-2), Alt (Line Out 3-4)

Headphone Output
- Two stereo

USB
- One USB 2.0 port (USB Type-C connector)

MIDI
- In, Out (two 5-pin DIN connectors)

Digital / Optical
- Two in, Two out

ADAT (S/MUX capable)
- 16 channels @ 44.1 to 48 kHz (fs1)
- 8 channels @ 88.2 to 96 kHz (fs2)
- 4 channels @ 176.4 to 192 kHz (fs3)

S/PDIF (Toslink)
- Stereo at all sample rates

Microphone Input(s) - Channels 1-8
- Frequency Response: 20 Hz to 20 kHz, +0.1 dB
- Dynamic Range (A-weighted): 116 dB
- THD + Noise (1 kHz @ -1 dBFS): -110 dB (0.0003%)
- Maximum Input Level: 14 dBu
- Input Impedance: 2 Kilohms
- Available Gain (Digitally-controlled): 60 dB
- Phantom Power: +48V (switchable)
- Connector Type: XLR Female, pin 2 positive

Instrument Input(s) - Channels 1-2
- Frequency Response: 20 Hz to 20 kHz, +0.04 dB
- Dynamic Range (A-weighted): 116 dB
- THD + Noise (1 kHz @ -1 dBFS): -87 dB (0.004%)
- Maximum Input Level: 12.5 dBu
- Input Impedance: 1 Megohms
- Available Gain (Digitally-controlled): 60 dB
- Connector Type: 1/4" TS unbalanced

Line Input(s) - Channels 1-8
- Frequency Response: 20 Hz to 20 kHz, +0.05 dB
- Dynamic Range (A-weighted): 116 dB
- THD + Noise (1 kHz @ -1 dBFS): -108 dB (0.0004%)
- Maximum Input Level: 22 dBu
- Input Impedance: 10 Kilohms
- Available Gain (Digitally-controlled): 60 dB
- Connector Type: 1/4" TRS balanced or TS unbalanced

Line Output(s) - Channels 1-8
- Frequency Response: 20 Hz to 20 kHz, +0.1 dB
- Dynamic Range (A-weighted): 119 dB
- THD + Noise (1 kHz @ -1 dBFS): -111 dB (0.0003%)
- Maximum Output Level: 20.2 dBu
- Output Impedance: 100 Ohms
- Connector Type: 1/4" TRS balanced or TS unbalanced

Headphone Output(s) 1-2
- Frequency Response: 20 Hz to 20 kHz, +0.2 dB
- Dynamic Range (A-weighted): 116 dB
- THD + Noise (1 kHz @ -1 dBFS into >32Ω): -108 dB (0.0004%)
- Maximum Output Power into 32Ω: 225 mW
- Maximum Output Power in 600Ω: 35 mW
- Connector Type: 1/4" TRS stereo unbalanced

Included UA Software

- LUNA Digital Audio Workstation (Featuring Volt 876 remote-control integration and AI-powered tools)
- Teletronix LA-2A Tube Compressor
- UA 1176 Classic FET Compressor
- Pultec Passive EQ Collection
- Century Tube Channel Strip
- Oxide Tape Recorder
- Verve Analog Machines Essentials
- Pure Plate Reverb
- Galaxy Tape Echo
- PolyMAX Synth
- Showtime '64 Tube Guitar Amp

Included 3rd Party Software

- Ableton Live Lite
- Melodyne Essential by Celemony
- Ampeg® SVT-VR Classic Bass Bundle by Plugin Alliance
- Marshall® Plexi Classic Amp Bundle by Softube
- Virtual Drummer DEEP by UJAM
- Virtual Bassist DANDY by UJAM
- LABS by Spitfire Audio
